Harp Series MH8
Professional 100V Line Outdoor Speaker for Clear Voice Announcements
CSC Audio MH8 is a Weatherproof Column Horn Speaker designed for clear and powerful voice announcements across indoor and outdoor environments. Featuring dual 5-inch weather-sealed transducers, re-entrant flare technology and a 100V line transformer with multiple power taps, the MH8 provides reliable speech intelligibility and wide-area coverage for professional public address applications.
MH 8 is Engineered for high-intelligibility outdoor public address; this commercial loudspeaker combines crisp voice projection with rugged, all-weather durability. Loaded with dual 5" weather-sealed transducers and a high 96 dB sensitivity, with a 50W RMS (200W Peak) power handling. Its tailored 140 Hz to 14 kHz frequency response cuts cleanly through ambient noise across a focused 70-degree conical dispersion.
Built to withstand severe environments, it features a UV-resistant aluminum enclosure with marine-grade stainless steel hardware. Integrated 8-ohm and multi-tap 100V transformer connections provide flexible system routing, while the heavy-duty adjustable mounting bracket ensures precise aiming and secure installation.
Clear Voice Announcements for Outdoor Applications
Built for demanding commercial and outdoor installations, the MH8 combines a UV-resistant aluminum housing, marine-grade stainless-steel hardware and an adjustable heavy-duty mounting bracket for long-term performance in challenging environments.
FEATURES AND APPLICATIONS
Key Features
- 50W RMS / 200W Peak Power Handling
- 100V Line Transformer with Multiple Power Taps
- Dual 5" Weather-Sealed Transducers
- 99 dB High Sensitivity Output
- UV-Resistant Aluminum Housing
- Marine-Grade Stainless Steel Hardware
- Weatherproof Design for Outdoor Installations
- Adjustable Heavy-Duty Mounting Bracket
- Wide Dispersion Coverage for Clear Announcements
Applications
- Educational Campuses
- Commercial Complexes
- Stadiums
- Parking Areas
- Transportation Hubs
- Any Public Address
Technical Specification
| MODEL | MH8 |
|---|---|
| Type | Weather-sealed / Re-entrant Flare Speaker |
| Design | Weatherproof for Announcements |
| Power Rating (RMS) | 50 W |
| Power handling | 50W RMS / 200W Peak Power Handling |
| Impedance | 8 ohms/ 100V Line Transformer with Multiple Power Taps |
| Sensitivity | 96 dB |
| Driver | Dual 5" Weather-Sealed Transducers |
| Maximum SPL | 116 dB |
| Frequency Response | 140 Hz to 14khz |
| Dispersion Coverage | Conical 70 degree |
| Transducer Configuration | Dual 5", weather-sealed / re-entrant flares |
| Housing Material | Extruded 6063-T5 Structural Aluminum Chassis |
| Hardware | Marine-Grade Stainless Steel Hardware |
| Finish | UV-resistant Polyester Architectural Powder Coat (RAL 7035 Light Grey / White) |
| Grilles & Mesh | Perforated aluminum end-grilles lined with hydrophobic stainless steel micro-mesh |
| End-Cap Seals | Die-cast aluminum endcaps with continuous EPDM O-ring compression gaskets |
| Internal Damping | Self-adhesive viscoelastic butyl damping pads applied to inner extrusion walls to suppress metallic panel resonance |
| Fasteners | 316 Stainless Steel (A4-70 marine grade) |
| Mounting System | Adjustable Heavy-Duty Mounting Bracket |
| Selector Interface | Rear rotary switch or internal ceramic terminal block tap selector |
| Cable Connection | PG9 / M16 brass nickel-plated glands strain relief with rubber boot |
| Terminal Type | High-temperature ceramic 4-pin barrier block |
| Electrical & Wiring Interface |
Selector Interface: Rear rotary switch or internal ceramic terminal block tap selector
|
