Contrabass Series CR 210s
Engineered for Impact: Experience Bass Like Never Before!
CR 210 integrate seamlessly in small venues, including homes & other A/V applications. As the trend of discreet installations in interiors continues to grow, these sub-woofers are designed to be concealed and occupy minimal floor space.
A combination with the String or Cello series tops make a fabulous system, and it is recommended for use in situations where a user requires a low-end extension for ambient music. This unconventionally shaped neutral appearance can be installed on ceilings, against walls or hidden under seating. When used in multiples, they can cover a relatively large space & blends nicely with the interiors. The speakers are available in custom colours. CR 210s can be placed in a corner as a table, & it is a perfect fit for small venues, including homes & other AV applications. These cabinets are available in custom colours.
Contrabass CR 210s is a relatively small, 2x10" (254 mm) reflex-loaded sub-woofer designed for low visibility. By using minimal floor space and having discreet appearance, The Contrabass CR series seamlessly combines with String or Cello series loudspeakers. ST 23, ST 43, CF 5, CC 8.
Key Features
- Compact, high-performance, reflex-loaded dual 10" (254 mm) sub-woofer
- Fast, integral wall/ceiling mounting clamp
- Easy to install
- Can retrofit into existing venues
- Less than 9" tall, it can easily go under a stairway
Applications
- Restaurants
- A/V spaces
- Conference rooms
- Bars and lounges
- Gyms
- Homes
Technical Specification
| MODEL | CR 210s |
|---|---|
| Type | Compact, Reflex Loaded Sub-woofer |
| Frequency Response (1) | 48 Hz-250 Hz ± 3 dB |
| Drivers | LF: 2x10" (254 mm) with a 2" (50 mm) voice coil |
| Recommended Amplifier Upto | 1200 Watts |
| Sensitivity (1 W / 1 m) | 97 dB |
| Maximum SPL (9) | 121 dB continuous, 129 dB Max |
| Nominal Impedance | 4 Ohms |
| Dispersion | Omni |
| Crossover | LPF 110Hz |
| Enclosure | Baltic birch ply |
| Finish | Textured black |
| Protective Grill | Perforated steel |
| Connectors | 2 x Neutrik Nl4 |
| Pin Connections | Input: ± 1, Link through: ± 2 |
| Standard Colours | Black / White |
| Fittings | Integral feet |
| Horn | N/A |
| Rated Continuous Power AES | 600 Watts |
| Rated Maxium Power/Program Power | 1200 Watts |
| Peak Power | 2000 Watts |
| Accessories | NA |
| Dimensions - Product (in mm) | (W) 813 x (H) 272 x (D) 511 |
| Dimensions - Including packing (in mm) | (W) 837 x (H) 290 x (D) 536 |
| Net weight (kgs) | 28 |
| Shipping Weight (kgs) | 30 |
About Series
The Contrabass Series products capture the bold and dynamic characteristics of the contrabass. Choose between a Reflex, Multiload, or a bandpass; the Contrabass Series has it all. The aim is to deliver deep, impactful bass that defines the lower frequency extension of the audio spectrum, making them ideal for both live sound and installation applications. Engineered to ensure minimum cabinet resonance, they disappear in a venue and are in different shapes and sizes that fit under a stairway, stand next to a column, or simply can be slipped under a stage without losing the high-impact performance. These subwoofers enhance low-frequency extension and overall audio presence, making them perfect for high-energy environments. These are ideally paired with the Cello and String Series mid-highs. Choose from our range of Contrabass and String series subwoofers to play, hear, and feel the music.
