Contrabass Series RRH 218s
Engineered for Impact: Experience Bass Like Never Before!
This highly-efficient, multi-load, 1600 Watt dual 18 in sub-woofer with double suspension is the main system to be used with the Cello series top cabinets. The sub has been designed to kick without losing its extended low-frequency response. Suitable for use in fixed installation and mobile application, the RRH 218s is an extremely versatile sub-woofer for integrators. It has been specially designed for live bands and pounding nightclubs.
For demanding applications, the CSC Maestro MS 26 controller is configured to perform with its EQ and limiter functions are pre-loaded in the controller. CC 8, CF 10, CF 12, CF 15, CF 12h, RR 212h, RR 15h and RR 15hl are a perfect match for RRH 218s
Key Features
- Compact, high-performance, multi-load, dual 18" sub-woofer
- Easy to install
- Can retrofit into existing venues
- Standard accessories include top hat and rubber feet
Applications
- Nightclubs
- Live performances
Technical Specification
| MODEL | RRH 218s |
|---|---|
| Type | Multi loaded sub-woofer |
| Frequency Response (1) | 37 Hz-300Hz ± 3 dB |
| Drivers | LF: 2 x18" (450 mm) with a 4" (100 mm) voice coil |
| Recommended Amplifier Upto | 2500 Watts |
| Sensitivity (1 W / 1 m) | 106 dB |
| Maximum SPL (9) | 137dB continuous, 143 dB Max |
| Nominal Impedance | 4 Ohms |
| Dispersion | Omni |
| Crossover | LPF 100 Hz |
| Enclosure | Baltic birch ply |
| Finish | Textured black paint |
| Protective Grill | Perforated steel |
| Connectors | 2 x Neutrik Nl8 |
| Pin Connections | Input: ± 1, Link through: ± 2 |
| Standard Colour | Black / White |
| Horn | NA |
| Rated Continuous Power AES | 1600 Watts |
| Rated Maximum Power/Program Power | 3200 Watts |
| Peak Power | 6400 Watts |
| Accessories | Castors, Felted waterproof covers, Flying hardware |
| Dimensions - Product (in mm) | (W) 1190 x (H) 507 x (D) 899 |
| Dimensions - Including packing (in mm) | (W) 1214 x (H) 534 x (D) 921 |
| Net Weight (kgs) | 90 |
| Shipping Weight (kgs) | 96 |
About Series
The Contrabass Series products capture the bold and dynamic characteristics of the contrabass. Choose between a Reflex, Multiload, or a bandpass the Contrabass Series has it all. The aim is to deliver deep, impactful bass that defines the lower frequency extension of the audio spectrum, making them ideal for both live sound and installation applications. Engineered to ensure minimum cabinet resonance, they disappear in a venue and are in different shapes and sizes that fit under a stairway, stand next to a column, or simply can be slipped under a stage without losing the high-impact performance. These subwoofers enhance low-frequency extension and overall audio presence, making them perfect for high-energy environments. These are ideally paired with the Cello and String Series mid-highs. Choose from our range of Contrabass and String series subwoofers to play, hear, and feel the music.
